Axe series 2U GPU Servers
The AXE-7220 series is a family of 2U short-depth GPU servers engineered for demanding edge AI applications. With a chassis only 450 mm deep, these systems fit into tight spaces without compromising on performance. Each model supports a single high-end Intel Xeon or AMD EPYC processor for workstation-grade or server-class compute at the edge. Support for up to two full-size double-width GPUs enables accelerated AI inference, computer vision, machine learning, and edge analytics workloads.
Up to eight DDR5 DIMM slots provide the memory bandwidth needed for data-intensive processing. Hot-swappable fans and front-accessible SSD bays simplify maintenance while supporting continuous operation. The short-depth design is especially well suited for field cabinets, factory floors, mobile enclosures, and other constrained installations. Optional redundant power supplies and integrated BMC-based remote management improve uptime and serviceability for unmanned or remote edge deployments.
The AXE-7220 series is built for organizations that need powerful AI inference and data processing close to where data is generated. Its 2U short-depth 450 mm chassis makes deployment practical in shallow racks, telecom cabinets, industrial enclosures, and other edge locations where traditional servers are too deep.
Across the series, users can choose between Intel Xeon W, AMD EPYC 9004/9005, or Intel Xeon Scalable processor platforms while maintaining a common short-depth form factor and dual-GPU capability. This makes the platform suitable for applications such as machine vision, medical imaging, smart manufacturing, surveillance analytics, telecom edge computing, and mobile AI infrastructure.
Range features
A high level overview of what this range offers
- Compact 450 mm chassis: 2U short-depth design enables installation in shallow racks and space-constrained edge environments.
- Single-socket high-performance CPU platform: Available with Intel Xeon W, AMD EPYC 9004/9005, or 4th/5th Gen Intel Xeon Scalable processors.
- Dual full-length GPU support: Supports up to 2 FHFL double-width GPUs for AI inference, vision processing, and accelerated analytics.
- High-bandwidth DDR5 memory: Up to 8 DDR5 DIMM slots at up to 6400 MT/s for demanding edge workloads.
- Hot-swappable cooling and storage: Four quick-swap fan modules and front 2.5-inch hot-swap SSD bays simplify serviceability.
- Redundant power capability on selected models: AXE-7220SR includes dual redundant CRPS power supplies for higher availability.
- Integrated remote management: Built-in BMC with IPMI 2.0 and Redfish support enables out-of-band monitoring and control.
- Edge-ready connectivity: High-speed Ethernet options and 5G readiness support distributed and telecom edge deployments.
Downloads
for Axe series 2U GPU Servers
What’s in this range?
All the variants in the range and a comparison of what they offer
| Specification | AXE-7220GW | AXE-7220TR | AXE-7220SR |
|---|---|---|---|
Form Factor | 2U rackmount, short-depth 450 mm | 2U rackmount, short-depth 450 mm | 2U rackmount, short-depth 450 mm |
Processor Support | Single Intel Xeon 600-series workstation-class processor | Single AMD EPYC 9004/9005 series processor | Single 5th/4th Gen Intel Xeon Scalable processor |
Memory Capacity | Up to 8 x DDR5 DIMM slots, up to 6400 MT/s | Up to 8 x DDR5 DIMM slots, up to 6400 MT/s | Up to 8 x DDR5 DIMM slots, up to 6400 MT/s |
GPU / PCIe Slots | 2 x PCIe Gen5 x16 slots, supports 2 x FHFL double-width GPUs | 2 x PCIe Gen5 x16 slots, supports 2 x FHFL double-width GPUs | Up to 2 x PCIe Gen4 x16 or 5 x PCIe Gen4 x8 slots, supports 2 x FHFL double-width GPUs |
Storage Bays | 4 x 2.5-inch hot-swap SSD bays with SATA/NVMe support | 4 x 2.5-inch hot-swap SSD bays with SATA/NVMe support | 4 x 2.5-inch hot-swap SSD bays with SATA/NVMe support |
Networking | High-speed Ethernet, typically dual ports such as 10 GbE; exact configuration varies | High-speed Ethernet, typically dual ports such as 10-25 GbE; exact configuration varies | 2 x 25 GbE SFP28 plus 2 x 1 GbE built-in LAN ports, with optional 5G modem support |
Remote Management | AST2600 BMC with IPMI 2.0 and Redfish | BMC with remote IPMI support | BMC with IPMI 2.0 and Redfish |
Power Supply | Single AC PSU | Single AC PSU | Dual 100-240 V AC redundant CRPS power supplies |
FAQs
for Axe series 2U GPU Servers
All three models share the same 2U short-depth 450 mm chassis and support up to two full-length double-width GPUs, but they differ mainly by processor platform. AXE-7220GW is based on Intel Xeon W for workstation-class performance, AXE-7220TR uses AMD EPYC 9004/9005 for AMD-based server deployments, and AXE-7220SR uses 4th or 5th Gen Intel Xeon Scalable for enterprise server workloads. The SR model also offers flexible PCIe lane configurations and dual redundant CRPS power supplies.
Each AXE-7220 server supports up to two full-height, full-length, double-width GPUs. The GW and TR models provide 2 x PCIe Gen5 x16 slots, while the SR model supports up to 2 x PCIe Gen4 x16 or alternative Gen4 x8 slot configurations, depending on setup.
The series uses a high-density thermal design with four hot-swappable high-speed fan modules to maintain airflow across the CPU, GPUs, memory, and storage. This helps sustain stable operating temperatures even under heavy AI and accelerator workloads while simplifying field maintenance.
Yes, AXE-7220SR includes dual redundant CRPS power supplies for higher availability. The AXE-7220GW and AXE-7220TR are specified with single AC power supplies in the provided information.
Yes. The AXE-7220 series includes an onboard BMC for out-of-band management. Support includes IPMI 2.0 and Redfish on listed models, enabling remote monitoring, power control, health checks, and maintenance in unmanned or remote edge environments.
Networking varies by model. The AXE-7220SR includes 2 x 25 GbE SFP28 and 2 x 1 GbE ports, with optional 5G modem support. The GW and TR variants are positioned for high-speed Ethernet connectivity as well, with exact port configurations depending on the specific model.
Each system provides 4 x 2.5-inch front-accessible hot-swap drive bays for SSD storage, with support for SATA and NVMe configurations. This allows flexible deployment for OS, caching, local data logging, and application storage at the edge.
The platform supports common x86-64 operating systems used in edge and enterprise deployments, including Windows Server and major Linux distributions such as Ubuntu and RHEL-compatible environments. As a barebone-style server platform, it gives users flexibility to install the OS and software stack that best fits their workload.
The AXE-7220 series is designed for edge AI and high-performance edge computing applications such as machine vision inspection, medical imaging analysis, telecom MEC, smart city analytics, transportation systems, defense platforms, and real-time video processing where compact deployment and GPU acceleration are both critical.
Yes. The AXE-7220SR is described as NVIDIA-Certified, indicating validated compatibility and performance for professional NVIDIA GPU deployments in AI edge computing environments.
