Extended area blackbody sources

Technology: IR blackbodies and test systems
Partner: Infrared Systems Development

Infrared Systems Development extended-area black-body emitters are flat plate emitters with particularly high emission capacity that achieve an average emission level of 0.96. These blackbodys are ideal when used in applications where the aperture of the cavity blackbody is too small.

Range features

A high level overview of what this range offers

Temperature range: from -30 °C up to 500 °C
Emitting area: up to 30cm x 30 cm
Wavelength range: 0.5 microns to 99 microns
Emissivity: up to 96%
Calibration traceable to NIST

Downloads

for Extended area blackbody sources

pdf

Infrared Systems Development – Blackbody Catalogue

Download

What’s in this range?

All the variants in the range and a comparison of what they offer

Model	Temperature	Emitter area
IR-2100/301	-5… 140°C	2 x 2 inches
IR-2101/301	-30… 75°C	2 x 2 inches
IR-2103/301	-5… 125°C	3 x 3 inches
IR-2106/301	5… 150°C	6 x 6 inches
IR-140/301	Ambient up to 230°C	12 x 12 inches
IR-160/301	Ambient up to350°C	12 x 12 inches
IR-150/301	Ambient up to 500°C	12 x 12 inches
