WNFQ-262ACNI(BT) Wi-Fi 5 & Bluetooth 5.0 M.2 Module
- Technology
- Wi-Fi modules
- Partner
- SparkLAN
The SparkLAN WNFQ-262ACNI(BT) is an industrial-grade QCA6174A B-Key module supporting 802.11ac/a/b/g/n dual-band Wi-Fi + Bluetooth in an M.2 2242 form factor. Based on the Qualcomm Atheros QCA6174A chipset, this highly integrated module offers seamless roaming and advanced security for enterprise and industrial applications.
It supports IEEE 802.11ac/a/b/g/n with 2×2 (2T2R) MIMO, delivering speeds up to 300 Mbps on 802.11n and 867 Mbps on 802.11ac (Wi-Fi 5). The module provides a PCIe interface for Wi-Fi and a USB interface for Bluetooth, with a wide operating temperature range (-40°C ~ +85°C) for industrial environments.
Range features
A high level overview of what this range offers
- Dual-band Wi-Fi 5 (802.11ac/a/b/g/n) + Bluetooth
- Qualcomm Atheros QCA6174A chipset
- M.2 2242 B-Key form factor
- 2×2 (2T2R) MIMO technology
- 2.4 GHz and 5 GHz bands
- Up to 300 Mbps (802.11n) and 867 Mbps (802.11ac)
- PCIe interface for Wi-Fi, USB interface for Bluetooth
- Seamless roaming for enterprise use
- Industrial-grade operating range (-40°C ~ +85°C)
- Advanced security: WEP, WPA, WPA2, WPA3, 802.1X
What’s in the range?
All the variants in the range and a comparison of what they offer
| Category | Specification |
|---|---|
Wi-Fi | IEEE 802.11ac/a/b/g/n |
Bluetooth | Bluetooth V4.2, V4.1, V4.0 LE, V3.0+HS, V2.1+EDR[/role_based_content] |
Chipset | Qualcomm Atheros QCA6174A-5 |
Host Interface | WLAN : PCIe |
Antenna | 2 x IPEX MHF1 connectors 802.11ac/a/b/g/n ISM Band |
Operating frequency | 2.412GHz~2.484GHz 5.150GHz~5.850GHz |
