ABP/ ABP2 Pressure Sensor Series
- Technology
- Board mounted pressure sensors
- Partner
- Honeywell
These sensors are high accuracy, compensated/amplified 60 mbar to 12 bar | 6 kPa to 1,2 MPa | 1 psi to 175 psi, digital or analogue output, liquid media capable.
Available in a small size helping engineers reduce design and manufacturing costs while maintaining enhanced performance and reliability of the systems they design.
Designed to provide a simple, cost-effective, basic level of performance but high-quality solution for medical and industrial applications where high performance, stability, and accuracy are not critical.
Potential applications include dialysis equipment, blood analysis, centrofusion and oxygen and nitrogen gas distribution, HVAC devices, data storage, process controls, industrial machinery, pumps, food and beverage, and robotics.
Range features
A high level overview of what this range offers
- Total Error Band±1.5 %FSS
- Long-term stability: ±0.25 %FSS
- Accuracy: ±0.25 %FSS BFSL
- Temperature output available
- High burst pressures
What’s in this range?
All the variants in the range and a comparison of what they offer
| Model | ABP | ABP 2.0 |
|---|---|---|
Signaal output | Amplified | Amplified |
Output | digital (I2C, SPI), analog (Vdc) | digital (I2C, SPI), |
Pressure range | ±60 mbar to ±10 bar | 6 mbar to 12 bar |
Media | Wet or Dry Media | Wet or Dry Media |
Mounting | DIP, Leadless SMT, SMT | Leadless SMT |
Accuracy | ±0.25 %FSS | ±0.25 %FSS |
Total Error Band | ±1.5 %FSS | ±1.5 %FSS |
Pressure Reference | differential, gage | absolute, differential, gage |
Output | 14-bit digital I2C, SPI, Analog | 24-Bit Digital I2C SPI |
Supply Voltage | 3,3 or 5 Vdc | 1,8-3,6 Vdc |
Calibrated | Yes | Yes |
Temperature compensated | Yes | Yes |
Operating Temperature | -40°C to 85°C | -40°C to 110°C |
Compensated Temperature | 0°C to 50°C | -40°C to 110°C |
