LPS360-M Series

The LPS360-M series of open-frame AC-DC power supplies comprises five single output models, offering voltages of 12 V, 15 V, 24 V, 36 V or 48 V. Each power supply also provides 12 V fan and 5 V standby outputs. Comprehensive overcurrent, overvoltage and overtemperature protection is provided as standard.

Additional facilities include main output remote sense, Power fail signal and I2C for basic monitoring and control. LPS360-M power supplies have a full load efficiency of up to 92%. Depending on operating conditions, they provide up to 240 W of output power with free air convection cooling and up to 360 W with 400 LFM of forced air. Less than 1U high, the power supplies are ideal for light industrial systems as well as patient contact Type BF medical applications.

LPS360-M Series

Range features

  • 3” x 5” footprint
  • Less than 1U high
  • EN61000-3-2 compliant
  • 12 V fan output
  • LPX200 enclosure kit available
  • 5 V Standby output
  • Remote Inhibit
  • PMBus commands
  • RoHS compliant
  • Digital I2C interface
  • Designed to meet Class I and Class II
  • Dual AC fuses
  • Suitable for BF Type applications

Range benefits

  • Medical and ITE safeties
  • Active power factor correction
  • Remote sense
  • Power fail
  • Adjustable main output
  • Level B Conducted EMI – Class I or Class II inputs
  • Overvoltage protection
  • Overload protection
  • Thermal overload protection

Downloads

for LPS360-M Series

pdf
AE LPS360-M Series
Download

What’s in this range?

All the variants in the range and a comparison of what they offer

Model NumberMin. Voltage (V)Max. Voltage (V)Current (A)Nominal Voltage (V)Number of Outputs

LPS363-M

12

13.8

30

12

1

LPS364-M

14.25

16.5

24

15

1

LPS365-M

24

27.6

15

24

1

LPS366-M

30.6

36

11.25

36

1

LPS368-M

45.6

52.8

7.5

48

1

General product specifications:

SpecificationsValue

Output Power (W):

360

Length (Inches):

5

Width (Inches):

3

Height (Inches):

1.37

Mounting Type:

Embedded PSU

Minimum Output Current (A):

0 (zero)

Maximum Output Current (A):

30

Output Voltage Range (V):

12V to 52.8V

Minimum Output Power (W):

200

Maximum Output Power (W):

360

Maximum Input Voltage (V):

264

Warranty (Years):

2
