NeoPower configurable series
- Technology
- Modular / configurable power supplies
- Partner
- Artesyn / Advanced Energy
The Advanced Enery NeoPower NP08 AC-DC configurable power supply introduces best-in-class power density of 18 W/in3. For up to 4000 W output power,
NP08 is easy to configure (series or parallel) and has 8 output power slots. NP08 can drop into an OEM’s enclosure to make a custom power supply or simply be used for its high flexibility for any embedded or power conversion challenge requiring multiple outputs.
Features
- High power density, 18 W/in3
- Multiple digital communication protocol options via dongles
- Programmable as a voltage or a current source.
- Market-leading low ripple noise
- User Configurable
- Medical IEC/EN 60601-1 3.2 Compliant and BF Rated
- Semi F47
- Simplified buss bar design
Benefits
- More power in 2.5" configurable
- Flexible communications
- Fast Deployment
- Higher power signal and accuracy
- Easy-to-configure modules
- Certified Industrial & Medical applications
- Configurable buss bars for any series/parallel combination
- Confidence in reliability from the #1 configurable power supply manufacturer
Downloads
for NeoPower configurable series
| Specifications | Values |
|---|---|
Output Power (W): | 4000 |
Length (Inches): | 11.2 |
Width (Inches): | 8 |
Height (Inches): | 2.5 |
Mounting Type: | Configurable |
Minimum Output Current (A): | |
Maximum Output Current (A): | 448 |
Output Voltage Range (V): | 250 |
Minimum Output Power (W): | |
Maximum Output Power (W): | 448 |
Maximum Input Voltage (V): | 264 |
Warranty (Years): | 5 |
