Switch-mode transformers
Partner
JQH - Shenzen JingQuanHua Electronics Co. Ltd

Designed to meet switching power supply standards, the JQH planar transformer is compliant with CCC, UL, CE, and other international certifications. Featuring a compact planar transformer with small size and low height, it is fully customisable to meet specific performance requirements.

Switch-mode Transformer
IntroFeaturesContact
  • Input voltage range 100-240V AC, supporting global voltage standards
  • Frequency Compatible with both 50Hz and 60Hz power grids
  • Circuit switching frequency 29kHz–130kHz, suggesting a switching-mode power supply (SMPS) for efficient energy conversion
  • Output power 20W, suitable for low-power electronic devices
  • Operating temperature -40℃ to 85℃, indicating suitability for extreme environments
  • Storage temperature -40℃ to +105℃, ensuring resilience during storage and transport
  • Pin type Customisable, allowing flexibility in design and connection
  • Appearance dimensions Customisable, adaptable to specific form factor requirements
