Industrial Panel Computer
Adlink’s industry leading industrial panel computer is a rugged, easy to deploy COTS (commercial off the shelf) computing solutions. They range covers IP69K and IP65 products, and open frame solutions.
The industrial panel computer offers a wide range of processor performance with 7”,10.1”,12.1”,15",15.6” , 17”,18”, 19”,21.5" and 23.8" panel sizes to best suit versatile industrial and manufacturing applications, making these platforms the ideal solution in food and beverage, pharmaceutical, and automotive applications.
The modules are designed to be error free and durable even under critical environmental conditions. HALT (Highly Accelerated Life Testing) is at the heart of the design to ensure all products give long term reliability even in the harshest application.
All products integrate long life chipsets and TFT displays offering 5-15 year life cycles.
Range features
A high level overview of what this range offers
- All-in-one control panel and open frame
- Long life cycle
- Wide range ofpanel size
- Intel® Atom and Core I Series CPU’s
- VESA compatible and pipe mounting interface options
- Rugged design
- IP69K, IP65 compliant
- 10-point multi-touch P-CAP and resistive touchscreen options
- Wi-Fi and Bluetooth support
- PCIe x 16 expansion slot to provide custom expansion
Downloads
for Industrial Panel Computer
What’s in this range?
All the variants in the range and a comparison of what they offer
| Model | Screen size | CPU | Touchscreen | Mechanical size and weight (WxHxD) |
|---|---|---|---|---|
Titan-AL | 15.6”, 21.5”, 23.8” | Intel Atom X7-E3959 | PCAP | 15” 419x268x59.3mm, 8kg 21.5” 561x353x67.4mm, 12kg 23.8” 610x379x67.3mm, 12.8Kg |
Giant-B15/B17/B19 | 15”, 17”, 19” | Intel Atom E3845 | Resistive | 15” 408×314.1×107.2mm, 8.6kg 17” 438x354x107.2mm, 10.7kg 19” 465.1×390.6×107.2mm, 11.2kg |
Food-B15/B17/B19 IP69K | 15”, 17”, 19” | Intel Atom E3845 | Resistive | 15” 408×314.1x89mm, 8.6kg 17” 438x354x89mm, 10.7kg 19” 465.1×390.6x89mm, 11.2kg |
SP-KL series | 7”, 10.1”, 12.1”, 15.6”, 18.5”, 21.5” | Intel i7-7600U, i5-7300U, I3-7100U | 5 points capacitive or 1 point 5-wire resistive touch screen | |
SP-AL series | 7”, 10.1”, 12.1”, 15.6”, 18.5”, 21.5” | Intel Atom x5-E3930 , x7-E3950 | 5 points capacitive or 1 point 5-wire resistive touch screen |
