AmITX‑RL‑I industrial mini‑ITX motherboard
- Technology
- I-O & MB / Industrial motherboards
- Partner
- ADLINK
The ADLINK AmITX‑RL‑I is a powerful industrial Mini‑ITX motherboard designed to deliver exceptional performance and flexibility in a compact embedded platform. Built on the Intel® Q670 chipset, it supports Intel® Core™ 200S Series and 14th, 13th and 12th Gen Core™ i9/i7/i5/i3 processors with up to 65 W TDP, making it ideal for a wide range of compute‑intensive applications including edge AI, industrial automation, machine vision and embedded computing systems.
With support for PCIe 5.0 x16, high‑speed DDR5 memory, rich I/O and multiple expansion options, the AmITX‑RL‑I combines industrial‑grade reliability with cutting‑edge performance, empowering developers and system integrators to build next‑generation solutions with confidence.
Ideal use cases
-
Edge AI and Machine Vision Systems — High compute throughput with expandability for AI accelerators.
-
Industrial Automation & Control — Robust networking and legacy support for factory equipment.
-
Digital Signage & Multimedia Platforms — Multi‑display support with flexible graphics interfaces.
-
IoT Gateways & Embedded Platforms — Compact form factor and powerful processing for smart deployments.
Range features
A high level overview of what this range offers
-
High‑performance Intel® Core™ processor support Supports Intel® Core™ 200S Series and 14/13/12th Gen Core™ i9/i7/i5/i3 processors up to 65 W TDP for scalable performance across embedded and industrial workloads.
-
Dual‑channel DDR5 memory (Up to 64 GB) Dual‑channel DDR5 at 4800 MHz delivers higher memory bandwidth and performance for demanding applications and multitasking.
-
Quad independent displays Offers multiple display interfaces – HDMI 2.0b, HDMI 1.4b, DisplayPort 1.4a, and LVDS/eDP – enabling flexible visualisation and multi‑monitor support.
-
Advanced networking connectivity Dual GbE LAN (1× 1 GbE and 1× 2.5 GbE) enhances data throughput for industrial networks and high‑bandwidth system communication.
-
Extensive expansion options Includes PCIe 5.0 x16 slot for high‑performance add‑in cards, and multiple M.2 slots (B/E/M keys) supporting storage, wireless and other peripherals.
-
Comprehensive USB & legacy support Multiple USB 3.2 Gen2, Gen1 and USB 2.0 ports support modern peripherals, while legacy interfaces ensure compatibility with a broad range of industrial devices.
-
Flexible power input Supports both standard ATX 24+4 pin power and 12 V DC‑in for flexible system designs and power configurations.
-
Robust mini‑ITX form factor Compact 170 × 170 mm Mini‑ITX board ideal for space‑constrained industrial and embedded systems without sacrificing performance or I/O.
What’s in this range?
All the variants in the range and a comparison of what they offer
| Category | Details |
|---|---|
Processor Support | Intel® Core™ 200S Series & 14th/13th/12th Gen Core™ i9/i7/i5/i3 (up to 65 W TDP) |
Chipset | Intel® Q670 |
Memory | 2× DDR5 4800 MHz up to 64 GB |
Display Outputs | HDMI 2.0b, HDMI 1.4b, DisplayPort 1.4a, LVDS or eDP |
LAN | 1× 1 GbE, 1× 2.5 GbE |
Expansion Slots | 1× PCIe 5.0 x16 |
USB | USB 3.2 Gen2, Gen1 & USB 2.0 (multiple ports) |
M.2 Slots | 1× M.2 B‑Key, 1× M.2 E‑Key, 2× M.2 M‑Key |
Power Input | ATX 24+4 pin or 12 V DC |
Form Factor | Mini‑ITX (170 × 170 mm) |
