WNFQ-290BE(BT) Wi-Fi 7 Tri-band M.2 Module

The WNFQ-290BE(BT) is the first Qualcomm-based Wi-Fi 7 (802.11be) module in a standard M.2 2230 E Key form factor. It is backward compatible with IEEE 802.11 be/ax/ac/a/b/g/n standards and supports tri-band operation across 2.4 GHz, 5 GHz, and 6 GHz frequencies. It can operate in single-band mode on 2.4 GHz together with either 5 GHz or 6 GHz, and supports channel bandwidths up to 160 MHz.

This module is designed with two spatial streams (2T2R, or 2×2) and supports MU-MIMO for high-efficiency data transfer. Wi-Fi connectivity runs over PCIe, while Bluetooth operates over USB.

With its standard M.2 2230 E Key design, the WNFQ-290BE(BT) fits seamlessly into any platform that already has an M.2 E Key slot, requiring no changes to the host hardware design.

Software support includes Linux (open source) in the near future, and the module is compatible with both x86 and ARM-based platforms. It supports both STA mode and Soft AP mode*, making it well-suited for applications such as digital signage, point-of-sale systems, rugged computers and tablets, fanless industrial automation PCs, and other environments that demand reliable, high-speed wireless connectivity.

WNFQ-290BE(BT) Wi-Fi 7 Tri-band M.2 Module

Range features

A high level over view of what this range offers

  • Qualcomm-based Wi-Fi 7 (802.11be) module
  • Tri-band: 2.4 GHz, 5 GHz, 6 GHz
  • Supports 160 MHz channel bandwidth
  • Backward compatible with 802.11 be/ax/ac/a/b/g/n
  • 2×2 MU-MIMO (2T2R) design
  • Wi-Fi via PCIe, Bluetooth via USB
  • M.2 2230 E Key form factor
  • Compatible with x86 and ARM platforms
  • Supports STA mode and Soft AP mode*
  • Open-source Linux support (coming soon)
  • Fits existing M.2 E Key slots — no redesign needed
  • Suitable for digital signage, POS, rugged PCs/tablets, fanless automation, and industrial IoT

What’s in this range?

All the variants in the range and a comparison of what they offer

CategorySpecification

Wi-Fi

IEEE 802.11be/ax/ac/a/b/g/n(2T2R)

Bluetooth

Bluetooth V5.4,V5.3,V5.2, V5.1, V5.0, V4.2, V4.1, V4.0LE, V3.0, V2.1+EDR

Chipset

Qualcomm QCC2073

Host Interface

WLAN : PCIe

Bluetooth: USB

Antenna

2 x IPEX MHF4 connectors

Main:WiFi

Aux: WiFi/BT

Operating Frequency

802.11be/ax/ac/a/b/g/n ISM Band

2.400GHz~2.4835GHz

5.150GHz~5.850GHz

5.925GHz~7.125GHz
