AP71582R Bluetooth 5.3 & 802.15.4
- Technology
- Wi-Fi and Bluetooth modules
- Partner
- SparkLAN
SparkLAN Technology presents the AP71582R, a compact, low-cost, and highly integrated wireless module designed to enable multiprotocol 2.4 GHz IoT connectivity. Engineered for applications such as building automation, medical monitoring, industrial control, smart lighting, smart locks, and asset tracking, this module offers powerful wireless performance in a small form factor.
The AP71582R supports Thread, Zigbee 3.0, IEEE 802.15.4g, and proprietary 2.4 GHz protocols, including multi-rate FSK and OQPSK-based modulations. It is optimized for ultra-low power communication, making it ideal for battery-powered devices in energy-sensitive environments such as factory automation and transport systems.
This highly integrated wireless MCU module is purpose-built to meet the demands of smart home and industrial IoT applications that require robust connectivity, small size, and energy efficiency.
Range features
A high level overview of what this range offers
- Supports multiprotocol 2.4 GHz wireless communication
- Compatible with Zigbee 3.0, Thread, IEEE 802.15.4g, and proprietary 2.4 GHz protocols
- Supports multi-rate FSK and OQPSK-based modulations
- Optimised for ultra-low power operation
- Compact, cost-effective design for space-constrained IoT applications
- Ideal for building automation, smart lighting, smart locks, and home automation
- Suited for medical, industrial, and transport/asset tracking use cases
- Enables reliable connectivity in factory automation and control environments
What’s in the range?
All the variants in the range and a comparison of what they offer
| Category | Specification |
|---|---|
Product description | Zigbee® 3.0 and 802.15.4 Multi-Protocol RF module |
Temperature range | -40~ 85°C (operating) |
Humidity (non-condensing) | 10 ~ 80% (operating) |
Dimension (mm) | 12 x 12 (typical) mm x 1.65mm±0.2mm(Max.) |
Weight | 0.44g |
