A7169 Transceiver +20dBm, 500kbps, QFN-16
- Technology
- ISM proprietary radios and SoCs
- Partner
- Amiccom
The Amiccom A7169 is a low-power, high-performance sub-1GHz wireless transceiver IC designed for short-range wireless communication applications such as Wireless M-Bus, Tire Pressure Monitoring Systems (TPMS), and home automation.
It is packaged in a compact QFN 3×3 mm 16-pin form factor and optimised for minimal power consumption. The A7169 integrates advanced features including Automatic Frequency Compensation (AFC) and a robust demodulator capable of tolerating data rate errors up to ±12%, ensuring reliable data reception even under challenging RF conditions.
Range features
A high level overview of what this range offers
- Sub-1GHz wireless transceiver chip
- Supports FSK and GFSK modulation
- Operates in sub-1GHz ISM bands (315, 433, 868, 915 MHz)
- Compact QFN 16-pin 3×3 mm package for space-saving designs
- Low power consumption for extended battery life
- High transmit power: +20 dBm
- High receiver sensitivity: −108 dBm @ 100 kbps
- Automatic Frequency Compensation (AFC) for crystal drift correction
- Demodulator tolerance up to ±12% data rate error
- Typical operating voltage: 3.3 V
- Typical transmit current: ~70 mA @ 19.1 dBm
- Suitable for Wireless M-Bus, TPMS, home automation, and industrial control applications
