RUTX11 4G Cat-6 Ethernet Wi-Fi Router
- Technology
- Cellular modems and gateways
- Partner
- Teltonika Networks
The Teltonika RUTX11 is a robust industrial LTE Cat 6 router designed to meet the needs of professional applications that demand high-speed, reliable connectivity. With support for Carrier Aggregation, this router delivers cellular speeds of up to 300 Mbps, ensuring fast data transmission for demanding environments. Equipped with four Gigabit Ethernet ports, dual-band Wave-2 802.11ac Wi-Fi, and Bluetooth LE, it offers flexible connectivity options for a wide range of use cases.
The RUTX11 also features dual SIM with auto-failover capabilities, ensuring uninterrupted connectivity by switching between networks as needed. Certified with EN 45545-2, the router is approved for use in passenger trains across Europe, making it ideal for transportation and other mission-critical applications.
This versatile router is perfect for industrial IoT, smart city infrastructure, and public transportation systems where dependable, high-performance networking is essential.
Range Features
An overview of what’s in the range
-
High-Speed LTE Connectivity – The RUTX range offers up to LTE Cat 6 speeds with Carrier Aggregation, delivering fast and reliable cellular data speeds up to 300 Mbps, ensuring seamless connectivity for data-intensive applications.
-
Dual SIM with Auto-Failover – The routers come with dual SIM functionality, supporting auto-failover, backup WAN, and other intelligent switching scenarios, ensuring constant network availability.
-
Gigabit Ethernet Ports – Each router in the range is equipped with multiple Gigabit Ethernet ports (up to 4 ports), providing high-speed wired connections for robust data transfer across multiple devices.
-
Advanced Wireless Capabilities – Featuring Wave-2 802.11ac Dual Band Wi-Fi and Bluetooth LE for strong wireless coverage and additional connectivity options, making it suitable for industrial, transportation, and public applications.
-
Rugged Industrial Design – Built for harsh environments, the RUTX series offers IP30-rated metal housing and wide operating temperature ranges, ensuring performance under extreme conditions.
-
EN 45545-2 Certification – Select models, like the RUTX11, are certified for use in passenger trains across Europe, making them ideal for transportation and other industries requiring strict safety standards.
-
Advanced Security Features – Equipped with enterprise-level firewall, VPN, and security protocols to ensure secure, encrypted communications, protecting sensitive data transmissions.
-
Easy Management with Remote Access – Teltonika Remote Management System (RMS) support allows for seamless monitoring, configuration, and troubleshooting, making device management more efficient for large-scale deployments.
Downloads
for RUTX11 4G Cat-6 Ethernet Wi-Fi Router
RUTX11 Flyer
| Category | Specification |
|---|---|
Mobile | 4G LTE Cat 6 up to 300 Mbps DL / 50 Mbps UL, 3G up to 42 Mbps DL / 5.76 Mbps UL |
3GPP Release | Release 12 |
SIM Card Support | Dual SIM, auto-switch features for weak signal, data limit, roaming, etc. |
Wireless | Dual-band 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with speeds up to 867 Mbps; supports 150 simultaneous connections |
Ethernet Ports | 1 x WAN, 3 x LAN (all 10/100/1000 Mbps) |
VPN Support | OpenVPN, IPsec, GRE, PPTP, L2TP, SSTP, WireGuard, ZeroTier, and more |
Security | Firewall, DDOS protection, VLAN support, SSL certificate generation, web filtering, and flexible access control |
Routing | Static and dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP), policy-based routing |
9 – 50 VDC, reverse polarity and surge protection, passive PoE through LAN1 (9 – 50 VDC) | |
I/O Ports | 1 x Digital Input (0 – 6V logic low, 8 – 30V logic high), 1 x Digital Output (max 30V, 300mA) |
GNSS | GPS, GLONASS, BeiDou, Galileo, QZSS |
-40°C to 75°C | |
Dimensions | 115 x 44.2 x 95.1 mm |
Certification | CE, FCC, RCM, UL/CSA, Railway standards, E-mark |
Network Protocols | TCP, UDP, IPv4/IPv6, ICMP, DNS, HTTPS, FTP, SSH, SNMP, MQTT, and many more |
Firmware | RutOS (based on OpenWrt), with support for custom firmware and additional package installation |
