RUT956 4G CAT-4 Router

The RUT956 is a robust industrial router that offers seamless connectivity through cellular, Wi-Fi, and wired interfaces, with automatic WAN failover to ensure uninterrupted internet access. It features GNSS capabilities for precise location tracking and includes serial communication ports for easy integration with a wide range of industrial devices.

With digital I/Os and the advanced RutOS operating system, the RUT956 supports automation, remote equipment control, and real-time event notifications.

RUT956 4G CAT-4  Router

Range features

An overview of what’s in the range

  • Connectivity – 4G LTE (Cat 4), 3G, 2G

  • Dual SIM – Auto-failover, backup WAN, and flexible switching

  • Multiple interfaces – Ethernet, RS232/RS485, and digital I/Os

  • GNSS – Location tracking and time sync via global satellite systems

What’s in this range?

All the variants in the range and a comparison of what they offer

CategorySpecification

Mobile module

4G LTE Cat 4 up to 150 DL/50 UL Mbps; 3G up to 21 DL/5.76 UL Mbps; 2G up to 236.8 DL/236.8 UL kbps

3GPP Release

Release 11

SIM switch

2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection

Status

IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC

SMS

SMS status, SMS configuration, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP

USSD

Supports sending and reading Unstructured Supplementary Service Data messages

Block/Allow list

Operator block/allow list (by country or separate operators)

Multiple PDN

Possibility to use different PDNs for multiple network access and services

Band management

Band lock, Used band status display

SIM PIN code management

SIM PIN code management enables setting, changing, or disabling the SIM card’s PIN

APN

Auto APN

Bridge

Direct connection (bridge) between mobile ISP and device on LAN

Passthrough

Router assigns its mobile WAN IP address to another device on LAN
