WP7607 4G Cat-4 LGA module

The WP7607 module, part of the WP Series, delivers secure and scalable device-to-cloud connectivity for IoT applications. Designed for Linux-based development, it features an integrated application processor running the Legato® framework, a comprehensive set of edge and cloud APIs, an optional GNSS receiver, and a power-efficient cellular modem. This LTE Cat-4 smart module simplifies system design and accelerates time to market, making it an ideal choice for transportation, telematics, public safety, and industrial IoT solutions.

WP7607 4G Cat-4 LGA module

Range features

An overview of what’s in the range

  • Ready-to-connect – Instant access to AirVantage Smart Connectivity reduces TCO, strengthens security, and simplifies management (optional)

  • Common form factor – Compact CF3® design ensures easy migration and future-proofing across technologies

  • Application processing – Dedicated ARM core processor running Legato® open-source software for flexible application development

  • FOTA upgrades – Free firmware-over-the-air (FOTA) updates keep deployments secure and future-proof

  • Cloud connected – Securely collect data and manage IoT deployments with integrated AirVantage® cloud services

  • Secure Boot – Prevents unauthorised code, ensuring secure connectivity

  • Ultra-Low power mode – Reduces power consumption by 200x for battery- or solar-powered applications

  • Location services – Integrated GNSS receiver enables location tracking and services (optional)

  • Industrial-grade – Tested for extreme temperatures and harsh environments

  • Network switching – Switch between networks with up to three certified firmware variants on board

  • VoLTE – Add voice commands or call capabilities to IoT applications

CategorySpecification

4G LTE

Cat-4

Frequency bands

B1, B3, B7, B8, B20, B28

EDGE, GSM, GPRS

900, 1800

Peak download rate

150Mbps

Peak upload rate

50Mbps

Satellite systems

Optional: GPS, Galileo, Glonass, BeiDou

Application core

ARM® Cortex™- A7 (1.3GHz)

Telecom Core

QDSP6

Firmware

Secure boot, Pre-certified firmware

Embedded platform

Legato® open source

Linux distribution

Yocto, Long-term supported Linux Kernel (LTSI)

Audio

Codec: HR, FR, EFR, AMR, Echo Cancellation & Noise Reduction (Optional), Digital Audio, DTMF, I2S, PCM, VoLTE (SKU dependent)

System drivers

Windows® 7, Windows® 8, Windows® 10, Linux Driver: Standard ECM

CF3 Form Factor

LGA, Snap-in socket option

Dimensions

22x23x2.5mm

Antenna

Diversity, MIMO

Temperature range

Industrial grade: -40°C / +85°C
