QT2021 Series MCXO Crystal Oscillators

The Q-Tech QT2021 MCXO range, where precision meets innovation in crystal oscillators. These microcomputer compensated crystal oscillators (MCXOs) represent the pinnacle of timing technology, utilising high-stability overtone SC-cut crystals combined with sophisticated microprocessor-controlled compensation.

The QT2021 series features a self-temperature sensing resonator and a dual-mode oscillator that work in harmony to virtually eliminate thermometry-related errors. This advanced design not only surpasses the traditional limitations of TCXOs and OCXOs but also sets a new standard for accuracy and reliability. Experience unparalleled performance and stability with the Q-Tech QT2021 MCXO range.

QT2021 Series MCXO Crystal Oscillators
  • Radiation Tolerant to 50kRad (Si)
  • Temperature Stability: ±10ppb to ±30ppb over temperature
  • Maximum aging: ±1.5ppm over 20 years
  • DC Power Input: 3.3Vdc, 90 milliwatts max
  • MIL-PRF-55310, Class 3 device (Discrete and Hybrid Technology)
  • G-Sensitivity 1PPB/G maximum
  • Custom design available tailored to meet customer’s needs
  • High reliability signal generator that provides Sine wave or HCMOS output
  • Designed to withstand radiation levels up to 50kRad (total dose), high shock, and vibration
  • Outputs: 5 to 80MHz and 1PPS.
  • Capability to sync to GPS at 1PPS or 10MHz
  • Environmental: Inherently rugged design capable of full military screening
  • Low Phase Noise and Jitter
  • Small Form Factor
