SFF transceivers comply with the Multiple Supplier Agreement (MSA) for either 2×5 or 2×10 pinning. The 2×7 pin layout follows the 2×5 MSA with an additional four pins that provide access to the digital diagnostic and rate select functions.
The transceivers use a single 3.3 V power supply and industry standard LVPECL for data transmission and TTL levels for control/indication with respect to Transmitter Disable or Signal Detect functionality.
The mini-SFF follows a 1×8 pinning footprint in a plastic package with metal shielding for excellent EMI performance in a miniature package.
Range features
A high level overview of what this range offers
- Transceivers for multi-mode and single mode fibre with dual or single fibre connector options (LC duplex or SC simplex)
- Superior optical and electrical performance optimised for low power dissipation requirements
- Commercial and industrial temperature ranges allow deployment of enhanced designs for mission critical applications
- 2×7 and 2×10 pinning include digital or analogue monitoring functions enabling link quality monitoring inside of networks
- Dual Tx and Dual Rx versions provide a unique, space-saving method of connecting applications that require unidirectional dataflow
- Standards-based designs for Fast/Gigabit Ethernet, Fibre Channel and SONET/SDH compliant links
- Customised housing, pinning or other enhancements available
- Data-rates from 10 Mb/s to 2.67 Gb/s
What’s in this range?
All the variants in the range and a comparison of what they offer
| Product family | Data rate (Gb/s) | Distances (km) | Dual Fiber / Bi-Directional | Wavelengths (nm) | DDMI / Monitoring | Temperature range (°C) |
|---|---|---|---|---|---|---|
2×5 SFF Transceiver | 0.1 to 2.67 | 0.5 to 120 | Both | 850 / 1310 / 1550 / CWDM | No | 0 to 70 / -40 to 85 |
2×7 SFF Transceiver | 0.1 to 1.25 | 0.5 to 15 | Dual Fibre | 850 / 1310 | Yes | 0 to 70 / -40 to 85 |
2×10 SFF Transceiver | 0.1 to 1.25 | 0.5 to 20 | Both | 850 / 1310 / 1550 | Yes | 0 to 70 / -40 to 85 |
1×8 Mini-SFF Transceiver | 0.1 to 1.25 | 0.5 to 10 | Dual Fibre | 850 / 1310 | No | 0 to 70 / -40 to 85 |
2×5 SFF Dual Tx / Dual Rx | 0.1 to 2.1 | 2 to 10 | Dual Channel | 1310 | No | 0 to 70 / -40 to 85 |
