FO Devices for Monitoring and Conditioning

AC Photonics range of Fibre Optic (FO) power monitoring products include a selection of photodiodes (PD), tap photodiodes, fibre scramblers, Single Mode (SM) to Multi-Mode (MM) fiber converters and collimators for single/dual/multi-fibre or Polarisation Maintaining (PM) fibre. Photodiodes are available as standard InGaAs PIN, high-linear InGaAs PIN, mini InGaAs PIN and a high-speed PIN for 800-900 nm. Tap photodiodes are available as uni- and bi-directional hybrid devices integrating a thin-film tap and PIN with tap ratios from 1-10%. The fibre scrambler and converter products are very suited for test and measurement and instrumentation applications.

FO Devices for Monitoring and Conditioning

Range features

A high level overview of what this range offers

  • Single/Dual/Multi-fibre collimators feature low insertion loss and low back reflection performance and are especially suited for laboratory use, collimation of laser beams and fiber-to-fibre coupling applications
  • SM to MM fibre converter available for 850 nm, 1310 nm, 1550 nm standard wavelengths or customised
  • Uni- and Bi-directional integrated tap detectors exhibit low insertion losses and polarisation dependent losses combined with a low dark current all in a very compact package
  • PM fibre collimators offer a high extinction ratio of 20 dB typical, 22 dB minimum and are available in single or multiple fiber configurations
  • Mini InGaAs PIN photodiode features a 300 µm active area with a wide operating wavelength range from 1000 to 1600 nm
  • The high-speed 800-900 nm PIN photodiode can be configured with either HI780, 50/125 or 62.5/125 fibre types or customised
  • The MM fibre scrambler features low insertion losses in both directions and provides fully filled mode distribution characteristics

Downloads

for FO Devices for Monitoring and Conditioning

pdf
AC Photonics – Products Brochure
Download
pdf
AC Photonics – Capabilities Component Design
Download
pdf
AC Photonics – Case Study Telecom Equipment
Download

What’s in this range?

All the variants in the range and a comparison of what they offer

Photodiode typeFibre pigtailWavelength range (nm)Typical applications

Highly Linear InGaAs

Bare Fibre, 900 µm Jacket

1000 to 1650

Communications Systems, Power Monitor, Analog Receivers

InGaAs PIN

Bare Fibre, 900 µm Jacket, Free Space

1000 to 1650

DWDM Power Monitoring, EDFA Gain and Power Monitor, OADM, OXC, Communications Systems

Mini InGaAs PIN

Bare Fibre, 900 µm Jacket

1000 to 1650

Communications Systems

High-Speed 860 nm PIN

Bare Fibre, 900 µm Jacket, Free Space

800 to 900

Communications Systems

Uni- and Bi-directional Tap

Bare Fibre, 900 µm Loose Tube

1270 to 1350,

1510 to 1590,

1570 to 1610,

1270 to 1350/1510 to 1610

EDFA Power Control, DWDM Monitoring, Network Switching

What’s in this range?

All the variants in the range and a comparison of what they offer

Product typeFibre typePigtail styleOperating wavelength (nm)Bandwidth (nm)

MM Fibre Scrambler

50/125, 62.5/125

Bare Fiber, 900 µm Loose Tube, 3mm Jacket, 2mm Jacket

850, 1310, 1550, Custom

±40

SM to MM Fibre Converter

50/125, 62.5/125, 100/140

Bare Fiber, 900 µm Loose Tube, 3mm Jacket, 2mm Jacket

850, 1310, 1550, Custom

±50

What’s in this range?

All the variants in the range and a comparison of what they offer

Collimator typeOperating wavelength (nm)Beam diameter / lens (mm)Fibre typeWorking distance (mm)

Single Fibre

1310±30, 1550±30, 1310/1550±30, 980/1550±30

≤ 0.45 / Փ1.8

≤ 0.35 / Փ1.0

SMF-28e, SMF-28e Ultra, Corning ZBL

1 to 70

Dual Fibre

1310±30, 1550±30, 1310/1550±30, 980/1550±30

≤ 0.45 / Փ1.8

≤ 0.35 / Փ1.0

SMF-28e, SMF-28e Ultra, Corning ZBL

1 to 70

Multi-Fibre

1310±30, 1550±30, 1310/1550±30, 980/1550±30

≤ 0.50 / Փ1.8

SMF-28e, SMF-28e Ultra, Corning ZBL

1 to 70

PM Fibre

1310±30, 1550±30, Custom

– / Փ1.8 Lens

– / Փ1.0 Lens

PM1310, PM1550

1 to 70
