Versatile Link – RedLink® Simplex Latching Plugs

The simplex latching plug is particularly suitable for applications demanding a good retention force such as high vibration environments. By simply applying a little pressure to the rear of the plug releases the latching mechanism.

Simple installation onto 2.2 mm Plastic Optical Fiber (POF) using industry standard tools. By following four easy steps, the plus can be fitted by electrical engineer without special training in optics:

  1. Strip jacket from cable using Firecomms POF cutter (PC-220F-410)
  2. Insert stripped POF into connector plug
  3. Crimp the plug onto the cable using crimp tool (FF-HTCRMP-1)
  4. Polish the fiber using polishing disc and paper (two steps, grit grades).
Versatile Link – RedLink® Simplex Latching Plugs

Range features

A high level overview of what this range offers

  • For use with Firecomms RedLink and Versatile Link transmitters and receivers in horizontal, vertical, and tilted housings
  • Available in both grey and blue colours
  • Wide operating temperature range: -40 to 85 °C
  • High retention force (connector to transmitter/receiver) of minimum 47N @ 25°C and 11N @ -40 to 85°C
  • Suitable for high-vibration applications
  • Cost effective method for termination in field installations or repair damaged cables simply
  • Maximum insertion force of 35N (connector to transmitter/receiver)
  • Use tools for installation provided by Firecomms or other industry standard versions

Downloads

for Versatile Link – RedLink® Simplex Latching Plugs

pdf
Firecomms – Cables and Plugs – Overview Brochure
Download
pdf
Firecomms – Overview Brochure
Download

What’s in this range?

All the variants in the range and a comparison of what they offer

ModelPlug TypeColourDurabilityFixing Method

FP-00C-XS0

Simplex Latching

Blue

Minimum 500 mating cycles

Crimp

FP-00C-YS0

Simplex Latching

Grey

Minimum 500 mating cycles

Crimp
