1U 12 Slots Mini Media Converter Rack Mount Chassis
- Technology
- Fibre optic cables, connectors and assemblies
- Partner
- Acal BFi
The 1U 12-slot media converter rack mount chassis is designed to house chassis-based mini media converters in a standard 19-inch rack. It allows multiple converters to be installed alongside network equipment, saving space and keeping cabling neat.
The chassis supports a universal AC/DC or DC/DC power supply, with an optional redundant power supply for high availability. An active/standby power configuration ensures reliable, uninterrupted operation.
Range features
A high level overview of what this range offers
- Compatible with standard 19-inch network and server racks
- 1U rack height with support for up to 12 mini media converter modules
- Designed to support multiple types of chassis-based media converters
- Enables centralised installation of media converters alongside network equipment
- Hot-swappable module design allows easy installation and replacement without service interruption
- Supports redundant power supply modules for high availability and reliable operation
- Active/standby power supply configuration ensures continuous, uninterrupted system operation
- Compatible with universal AC/DC or DC/DC power supply options
- Front and rear LED indicators provide clear visual status monitoring
- Improves rack space efficiency and keeps cabling organised and neat
- Ideal for data centres, enterprise networks, telecom rooms, and industrial applications
Downloads
for 1U 12 Slots Mini Media Converter Rack Mount Chassis
What’s in this range?
All the variants in the range and a comparison of what they offer
Input voltage | AC 100-240V 50/60Hz or/and DC 36-72V (48V typical) |
Output voltage | DC 12V |
Power output | 36 Watts maximum |
PWR | power supply (red) |
FAN | cooling FAN (green) |
Operating temperature | 0°C to 50°C |
Cooling | brushless DC fan |
Storage temperature | -20°C to +70°C |
Operating humidity | 90% max, non-condensing |
Case material | Iron |
Case colour | Black |
Net weight | 3.2kg approx. / unit |
Dimensions | 485 (W) x 270(H) x 44.5 (L) (mm) |
