iXon EMCCD Cameras

With the iXon EMCCD cameras, Andor has delivered a specialized, absolutely high-end yet affordable ultra-sensitive scientific camera platform specifically designed to make the absolute best use of EMCCD technology across all critical performance specifications and parameters.

Now available in the Ultra and Life series.

iXon EMCCD Cameras

What’s in this range?

All the variants in the range and a comparison of what they offer

Application Areas

  • SRRF-Stream for Super-Resolution Radial Fluctuations*
  • Single Molecule Detection*
  • Physiology / Ion Imaging & Cell Motility*
  • Spinning Disk Confocal Microscopy*
  • Bioluminescence Microscopy*

Benefits

  • Single-photon sensitivity*
  • Back-illuminated > 95% QE*
  • Fast frame rates*
  • Unique price-performance ratio*
  • The gold standard for single-molecule detection*
  • Preserve accurate cell physiology*
  • Available with the new super-resolution technology SRRF-Stream+*

Single Molecule Detection

Single molecule experiments present us with the considerable challenge of utilizing the limited photon budget of dynamic, single fluorescent molecules while simultaneously avoiding photobleaching. Andor iXon EMCCDs have continued to radically outperform sCMOS detectors in this most demanding of low-light applications.

Super-Resolution – SRRF-Stream+

SRRF-Stream+ is the latest version of our real-time super-resolution microscopy functionality that works on compatible Andor cameras. SRRF-Stream+ opens up the possibility of performing real-time super-resolution microscopy on conventional modern fluorescence microscopes. Depending on the image datasets, an improvement in resolution from 2- to 6-fold (50-150nm final resolution) can be expected. The latest version has been revised to provide even better image quality while retaining all the original advantages of SRRF-Stream.

Reduced phototoxicity

The iXon facilitates the use of the lowest possible excitation power while maintaining an excellent signal-to-noise ratio, thereby minimizing phototoxic effects. No other camera is as adept at preserving the physiological behavior of your cells over extended measurement periods.

Lowest fluorophore concentrations

In fluorescence microscopy, there is a continuous effort to achieve ever-lower fluorophore concentrations to avoid disturbing the physiology of the living cells being studied. The superior sensitivity of iXon facilitates the use of unprecedentedly low marker concentrations, thereby minimizing the "observer effect."

Single Photon Counting

iXon Ultra offers the absolutely lowest noise level possible, providing the degree of differentiation required to reliably detect and register single photon events, ideal for demanding quantum physics applications such as studies involving entangled photons.

Downloads

for iXon EMCCD Cameras

pdf
Andor iXon Life Overview
Download
pdf
Andor iXon Ultra Overview
Download

What’s in this range?

All the variants in the range and a comparison of what they offer

iXon Ultra & iXon Life Series

The iXon Ultra brings out the best in EMCCD technology.

When only the best is good enough. The market-leading EMCCD camera, Andor iXon Ultra, has long been recognized as the most powerful and versatile solution for the most demanding and low-light applications. Available for both physical and life science applications, the iXon Ultra offers unbeatable flexibility and functionality. It features market-leading TE cooling, ‘2-in-1’ EMCCD and CCD readout modes, and a host of other high-end features.

iXon Life, high performance at a low cost!

Andor’s latest iXon Life EMCCD platform is exclusively available for fluorescence microscopy applications and is designed to provide single-photon sensitivity with absolutely unrivaled price-performance. With unmatched sensitivity, iXon Life is perfect for single-molecule detection and live cell microscopy with minimal phototoxicity or photobleaching, but at a price not typically associated with high-performance EMCCD cameras.

Hardware featuresiXon UltraiXon Life

Conventional CCD amplifier

Yes

Integrated shutter

Yes

Minimum TE cooling temperature

-100°C

-80°C

Direct Data Access (CameraLink)

Yes

EMCCD mode Readout speeds (MHz)

888 Modell: 30, 20, 10 & 1

897 Modell: 17, 10, 5 & 1

888 Modell: 30 & 10

897 Modell: 17 & 10

Single photon counting modes

SRRF-Stream+ compatible

Yes

Yes

iXon Models 888 & 897

Each of the listed model types is available in both the ‘Ultra’ and ‘Life’ platforms.

Hardware featuresiXon 888iXon 897

Main attributes

Field-of-View, Sensitivity, and Frame Rate

Sensitivity and Frame Rate

Sensor Format (Pixel)

1024 x 1024

512 x 512

Sensor Diagonale

18.8 mm

11.6 mm

QE Options

BV (Life) or BV, EX2, UVB (Ultra)

BV (Life) or BV, EX2, UVB (Ultra)

Pixel size

13 µm

16 µm

Frame rate

26 fps (670 fps with 128 x 128 Crop Mode)

56 fps (595 fps with 128 x 128 Crop Mode)

Readout noise

< 1 e- with EM Gain

< 1 e- with EM Gain

Pixel well depth

80,000 e-

180,000 e-

Interface

USB 3.0

USB 2.0
