Advanced Energy’s SL Power SLB65 medically-approved AC-DC power supplies are available with a nominal main output of 5 V, 12 V, 15 V, 18 V, 24 V, or 48 V. SLB65 power supplies provide up to 65 W convection.
All models have output overvoltage, short circuit and overload protection and a small 2 x 3 x 1.2 inch form factor.
Features
- Small 2" X 3" x 1.2" size form factor
- 65 W convection cooled
- Universal input 80 to 264 VAC
- 2 x MOPP isolation
- -20˚C to 70˚C operating temperature range
Benefits
- For 1U applications
- Approved to UL/CSA/IEC/IEC60601-1, 3rd. Ed
- Meets 4th edition/heavy industrial EMC
- Approved To Ul/CSA/IEC/IEC62368-1
- 3 years warranty
Downloads
für SLB65 series
| Specifications | Value |
|---|---|
Output power (W) | 65 |
Length (inches) | 3 |
Width (inches) | 2 |
Height (inches) | 1.2 |
Mounting type | Embedded PSU |
Minimum output current (A) | 1.35 |
Maximum output current (A) | 8 |
Output voltage range (V) | 5V to 48V |
Minimum output power (W) | 40 |
Maximum output power (W | 65 |
Maximum input voltage (V) | 264 |
Warranty (years) | 3 |
| Model number | Min. voltage (V) | Max. voltage (V) | Current (A) | Nominal voltage (V) | Number of outputs |
|---|---|---|---|---|---|
SLB65S05C | 5 | 5 | 8 | 5 | 1 |
SLB65S05K | 5 | 5 | 8 | 5 | 1 |
SLB65S12C | 12 | 12 | 5 | 12 | 1 |
SLB65S12K | 12 | 12 | 5 | 12 | 1 |
SLB65S15C | 15 | 15 | 4 | 15 | 1 |
SLB65S15K | 15 | 15 | 4 | 15 | 1 |
SLB65S18C | 18 | 18 | 3.6 | 18 | 1 |
SLB65S18K | 18 | 18 | 3.6 | 18 | 1 |
SLB65S24C | 24 | 24 | 2.71 | 24 | 1 |
SLB65S24K | 24 | 24 | 2.71 | 24 | 1 |
SLB65S48C | 48 | 48 | 1.35 | 48 | 1 |
SLB65S48K | 48 | 48 | 1.35 | 48 | 1 |
