Radio Frequency Iron Powder Cores

Technologie
Pulverkerne
Partner
Micrometals

Hochfrequente weichmagnetische Materialien von Micrometals basieren auf Carbonyleisenpulvern. Sie eignen sich in einem wirklich weiten Frequenzband, in dem andere Materialien aufgrund einer Abnahme der Permeabilität (und somit Sättigung) oder erhöhter Verluste (und somit erhöhter Hitze und verringerter Effizienz) nicht verwendet werden können. Mit einem hohen Q-Faktor in Anwendungen bis zu 700MHz sind sie die perfekte Lösung für Induktivitäten und Transformatoren in Radio-, Video kommunikations- oder Breitbandanwendungen.

Der Permeabilitätsbereich (μr) reicht von 1 bis 35.

Radio Frequency Iron Powder Cores

Eigenschaften

  • Available in 11 different materials
  • Optimised for specific frequencies
  • Toroids available in core sizes from OD 1.27mm up to 165.1mm
  • Mix-2 preferred material for audio amplifiers filters and radio frequency
  • Available in toroid, E core, balun, hollow, bus bar, cup, disc, EH, EM, U, plain, rectangular, sleeve, and threaded core shapes
  • Customised shapes also possible
  • Mix-8 low core loss and good linearity under high bias conditions

Downloads

für Radio Frequency Iron Powder Cores

pdf
Micrometals radio frequency materials
Download
pdf
Micrometals Q curve brochure
Download
pdf
Micrometals product catalogue
Download

Verfügbare Modellvariationen

Alle verfügbaren Varianten und ein Vergleich ihrer Spezifikationen

Material mix no.PermeabilityTypical AL tolerance (%)Powder typeTemp coef of perm (+ppm/C°)Density gm/cm3 maxFrequency (MHz)Relative costColour code toroid

-0

1

N/A

Phenolic

N/A

N/A

N/A

1.3

Tan/tan

-1

20

±10

Carbonyl iron

280

6.4

10

3.8

Blue/clear

-2

10

±5

Carbonyl iron

95

5.0

45

2.2

Red/clear

-3

35

±10

Carbonyl iron

255

6.5

5.0

3.3

Gray/clear

-4

9

±5

Carbonyl iron

280

5.0

17

2.2

Blue/white

-6

8.5

±5

Carbonyl iron

35

5.0

55

3.6

Yellow/clear

-7

9

±5

Carbonyl iron

30

5.0

50

3.0

White/clear

-8

35

±10

Carbonyl iron

255

6.5

5.0

3.1

Yellow/red

-10

6

±5

Carbonyl iron

150

4.9

83

5.5

Black/clear

-15

25

±10

Carbonyl iron

190

6.4

7.0

3.4

Red/white

-17

4

±5

Carbonyl iron

50

4.8

170

3.5

Blue/yellow
