Les antennes du Système de positionnement global (GPS) / Système mondial de navigation par satellite (GNSS) permettent aux applications de suivi et de localisation d’accéder aux constellations de satellites GPS/GNSS. Abracon offre une large sélection de solutions GNSS/GPS/GLONASS/BeiDou, allant des petites antennes à puce céramique SMD avec polarisation linéaire aux patches directionnels polarisés circulairement et aux antennes externes dans différents supports. Les différentes options permettent une flexibilité pour orienter l’antenne dans le système GNSS afin d’assurer une plus grande précision de localisation, une meilleure fiabilité du verrouillage dans les zones urbaines et une meilleure réception du signal pour les cas d’utilisation standard et haute précision.

GNSS Antennas
IntroCaractéristiquesSpécificationsContact

Caractéristiques de la gamme

Un aperçu de haut niveau de ce que cette gamme offre

  • Plusieurs antennes fabriquées en ligne TS/IATF 16949
  • Classé IP67
  • Gain élevé
  • Précision de positionnement élevée
  • Support des protocoles GNSS/GPS/GLONASS/BeiDou
  • Solutions d’antennes puce, patches actifs et passifs, PCB flexible, antennes actives externes
  • Options de polarisation linéaire et circulaire
  • Options compactes, profil bas, haute-gain et résistantes aux intempéries
  • La collection comprend des antennes pour les bandes L2 et L5, telles que L1+L2+L5 patch empilé
  • Différentes options de montage disponibles : trou traversant, connecteur, surface, adhésif, magnétique et vis

Que contient cette gamme?

Toutes les variantes de la gamme et une comparaison de ce qu’elles offrent

Part numberDescriptionTypeProtocolLengthWidthHeight

ACAG0301-1575-T

MULTIBAND GNSS CHIP ANT SMD

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

3.2mm

1.6mm

0.6mm

ACAR0301-SG3

MULTIBAND GNSS CHIP ANT SMD

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

3.05mm

1.6mm

0.55mm

ACR1004GC

MULTIBAND GNSS+GPS(L5) CHIP ANT SMD

Internal/Embedded

GNSS

10mm

4mm

1.5mm

AEACBA045015-SG2

GPS/GLONASS PUCK ANT MAG SMA(M)

External

GNSS, GPS, GPS/GLONASS

45.2mm

35.8mm

15.2mm

AEACBA050018-SG3

MULTIBAND GNSS PUCK ANT ADH SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

50mm

50mm

18mm

AEACBA050018-SG4L2L5

GNSS/GPS L1+L2+L5 PUCK ANT ADH SMA(M)

External

GNSS, GPS, GPS L1/L2/L5/L6, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZS

50mm

50mm

18mm

AEACBA059015-C3GSW

COMBO 4G/LTE, GPS, WIFI, NBIOT/CATM PUCK 3XSMA

External

Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, GNSS, GPS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee

52mm

59mm

15mm

AEACBA081016-C2LG

COMBO GPS, 4G/LTE, NB IOT/CAT M PUCK 2XSMA

External

GNSS, GPS, Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M

81.6mm

16.2mm

N/A

AEACBD045015-SG2

GPS/GLONASS PUCK ANT MAG SMA(M)

External

GNSS, GPS, GPS/GLONASS

45.2mm

35.8mm

15.2mm

AEACBD050018-SG3

MULTIBAND GNSS PUCK ANT MAG SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

50mm

50mm

18mm

AEACBD059015-C3GSW

COMBO GPS, 4G/LTE, WIFI, NBIOT/CATM PUCK 3XSMA

External

GNSS, GPS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

52mm

59mm

15mm

AEACBD081016-C2LG

COMBO LTE/GPS ACTIVE PUCK ANT MAG 2xSMA(M)

External

GNSS, GPS, Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M

81.6mm

16.2mm

N/A

AEACBK046014-C2WG

COMBO GPS, WIFI PUCK ANT SCREW 2XSMA(M)

External

GNSS, GPS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, ISM

50mm

48mm

N/A

AEACBK050048-C2LG

COMBO GPS, 4G/LTE, NB IOT/CAT M PUCK 2XSMA

External

Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, GNSS, GPS, ISM

81.6mm

16.2mm

N/A

AEACBK110053-MLWG

COMBO GNSS, 2xLTE, 2xWIFI DOME SCW 5xSMA(M)

External

GNSS, GPS, GPS/GLONASS, Cellular, 4G/LTE, 4G/LTE MIMO, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, Wi-Fi/BT, Wi-Fi, Wi-Fi MIMO, BT/BLE/Zigbee, ISM

110mm

53mm

N/A

AEACBK189085-MLWFGL5

COMBO 2x4G/LTE, WIFI/BT/ZIGBEE, GPS, AM/FM

External

Cellular, 4G/LTE, 4G/LTE MIMO, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, ISM, GNSS, GPS, GPS L1/L2/L5/L6

189mm

182mm

85mm

AEACMK0660746-SG4

MULTIBAND GNSS DOME SCW TNC(F)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

76mm

66mm

N/A

AEAGMK148060-S1575

MULTIBAND GNSS DOME ANT SCW TNC-K

External

GNSS, GPS, GPS L1/L2/L5/L6, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

148mm

60mm

N/A

AEARBA048014-SG3

AUTO MULTIBAND GNSS PUCK ANT ADH SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou

48.5mm

47mm

14mm

AEARBD048014-SG3

MULTIBAND GNSS PUCK ANT MAG SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou

48.5mm

47mm

14mm

AECA0401G4Z

AUTO MULTIBAND GNSS PUCK ANT ADH SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

45.2mm

35.8mm

15.2mm

AECC0502GB

MULTIBAND GNSS HELICAL ANT CNTR SMA(M)

External

GNSS, GPS, GPS L1/L2/L5/L6, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

N/A

27.5mm

55.6mm

AECP0401G4Z

AUTO MULTIBAND GNSS PUCK ANT MAG SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

45.2mm

35.8mm

15.2mm

AECR1808A12

5-IN-1 COMBO GNSS, 2x5G, 2xWIFI DOME SCW 5xSMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, Wi-Fi MIMO, BT/BLE/ZigBee, Cellular, 5G, 5G MIMO, 4G/LTE, 4G/LTE MIMO, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

189mm

182mm

85mm

AECR1808A20

7-IN-1 GNSS, 4x5G, 2xWIFI DOME ANT SCW SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, Wi-Fi MIMO, BT/BLE/ZigBee, Cellular, 5G, 5G MIMO, 4G/LTE, 4G/LTE MIMO, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

189mm

182mm

85mm

AECS1806C03Z

AUTO 3-IN-1 GNSS, 4G/LTE, WIFI SHARKFIN 3xSMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

181.7mm

68.9mm

69.1mm

AECS1806D07Z

AUTO 4-IN-1 GNSS, 2x4G/LTE, WIFI SHARKFIN 4xSMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, Cellular, 4G/LTE, 4G/LTE MIMO, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

181.7mm

68.9mm

69.1mm

AECW0401G4Z

AUTO MULTIBAND GNSS PUCK ANT SCW SMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

46.6mm

N/A

16.3mm

AECW0801C03

3-IN-1 COMBO GNSS, 4G/LTE, WIFI PUCK SCW 3xSMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, Cellular, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

81.3mm

N/A

16.3mm

AECW0801C09

4-IN-1 COMBO GNSS, 2xLTE, WIFI PUCK SCW 4xSMA(M)

External

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, Cellular, 4G/LTE, 4G/LTE MIMO, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

81.3mm

N/A

16.3mm

AFAC120050-U6G

UWB, 5G/4G/LTE, WIFI, GNSS, ISM FPC ADH IPEX(F)

Internal/Embedded

UWB, Cellular, 5G, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, LoRa/SigFox, GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, BT/BLE/Zigbee, ISM

120mm

50mm

0.2mm

AFAG3030-SG3

MULTIBAND GNSS FPC ANT ADH IPEX(F)

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

30mm

30mm

0.2mm

AFAG4330-SG3

MULTIBAND GNSS FPC ANT ADH IPEX(F)

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

40mm

10mm

N/A

AFC8513U4G

5G/4G/LTE/NBIOT/CATM, GNSS FLEX ANT ADH IPEX(F)

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS, Wi-Fi/BT, Wi-Fi, BT/BLE/ZigBee, Cellular, 5G, 4G/LTE, 2G/3G/GSM, LPWA, NB-IoT/CAT-M, ISM

85mm

13.8mm

0.2mm

ANG4

NICHE GNSS L1

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

12mm

N/A

6mm

ANGH

NICHE GNSS L1 + L2 + L5 + L6

Internal/Embedded

GNSS, GPS, GPS L1/L2/L5/L6, GPS/GLONASS, GPS/GLONASS/BeiDou, GPS/GLONASS/BeiDou/Galileo/QZSS

15mm

N/A

8mm

APAE1575R1240ABDD1-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

12mm

12mm

4mm

APAE1575R1340ABDD6-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

13mm

13mm

4mm

APAE1575R1540AZDB2F-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

15mm

15mm

4mm

APAE1575R1820ABDC1-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

18mm

18mm

2mm

APAE1575R1840AADB7-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

18mm

18mm

4mm

APAE1575R1840BADB1F-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

18mm

18mm

4mm

APAE1575R2040ABDD2-T

1.575GHZ GPS CER PATCH ANT PIN

Internal/Embedded

GNSS, GPS

20mm

20mm

4mm

APAE1575R2520ABDD7-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

25mm

25mm

2mm

APAE1575R2540AADBE-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

25mm

25mm

4mm

APAE1575R2540BBDB1-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

25mm

25mm

4mm

APAE1590R1340AKDB2-T

GPS/GLONASS PATCH ANT PIN ADH

Internal/Embedded

GNSS, GPS, GPS/GLONASS

13mm

13mm

4mm

APAE1590R1350AKDB5-T

GPS/GLONASS PATCH ANT PIN ADH

Internal/Embedded

GNSS, GPS, GPS/GLONASS

13mm

13mm

5mm

APAE1590R2540AKDB1-T

GPS/GLONASS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS, GPS/GLONASS

25mm

25mm

4mm

APAEA1575R0940K14-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

9mm

9mm

4mm

APAES1575R1040J34-T

GPS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS

10mm

10mm

4mm

APAGM2704A-C2G

GPS/GLONASS ACTIVE PATCH ANT SMD IPEX(F)

Internal/Embedded

GNSS, GPS, GPS/GLONASS

27mm

27mm

4mm

APAGM3606-SG3

MULTIBAND GNSS PATCH ANT ADH PIN

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou

36mm

36mm

6mm

APAKC2506A-SG3

MULTIBAND GNSS ACTIVE PATCH ANT SMD IPEX(F)

Internal/Embedded

GNSS, GPS, GPS/GLONASS, GPS/GLONASS/BeiDou/Galileo/QZSS

25mm

25mm

6.9mm
